Model name: HNS117 3 in 1 dimmable motion sensor

This model is a multiple functions motion sensor, and microwave motion sensor, daylight sensor and CCT 3 in 1. You can choose the color temperature by DIP switch on requirement, and set the parameters by remote control. Easy operation and user friendly.

Advantage:

1. Tri-level dimmming, tunable white, daylight monitoring function by remote control setting (2 channels output)

2. Warm, Neutral and Cool three color temperature options

3. DIP switch and remote control setting

4. Customzied service: YES

Product information:

CCT Adjust

Cool: Long press to adjust the color temperature towards Cool , release to stop and lock down current color temperature.
Neutral: Press “Neutral” button, the color temperature will adjust to 50% cool + 50% warm.
Warm: Long press to adjust the color temperature towards Warm , release to stop and lock down current color temperature.

OCC OFF function
Press “OCC OFF” button, the motion sensor will be disabled.

Dim
Press “Dim” button to automatically dim up or down the light brighness during hold-time from 10% to 100%. Another press to lock it down when
desired brightness is achieved.

Reset function
Press “Reset” button, all sensor settings go back to factory default settings.
press “OCC ON” , “Reset” or “Ambient” to re-activate the motion sensor.

Factory default setting:

Sensitivity=100%
Daylight sensor=disable
Hold time=90s
Twilight time=5min
Twilight level=10%
CCT=Neutral

HYNALL INTELLIGENT CONTROL CO. LTD.

is a technology & innovation oriented team who persistently strive for all kinds of professional microwave motion sensor controls based on our 20 years+ experiences in industry, we focus ONLY on microwave motion sensing technology, to serve our customers with ultimate solutions that match best and save most!!

Why Hynall?

Although Hynall is 8 years only, we have the most experienced / professional  R&D team + Sales team, thanks to our rich experiences for more than 20 years in microwave motion sensor industry. Our R&D team firstly studied and introduced microwave technology into China for lighting use. From this point of view, we are proud enough to call ourself the industry pioneer, and we still keep that strengths with us till now.

What makes us stand out from others?

a)  Unlike many sensor manufacturers who also get themself involved in driver business or others, we focus only on our expertise--microwave products / solutions, we only do what we are really good at. Every product out of Hynall is microwave related, we seek for product diversity inside microwave industry only!

b)  We have a comprehensive range of all series including antenna modules, digital antennas, AC input versions, DC input versions, VR adjustable versions, remote control versions, detached versions, daylight harvesting version, and so on.

c)  With such professional + well experienced R&D + Sales team, we understand deeply of different lighting fixture types and various sensor applications, enable us to offer customers with best product selection, trouble shooting and after sales service.

d)  We are fast-responding and very flexible for all kinds tailor made products.
