    DC 12-30V Microwave Motion Sensor Module 5.8GHz C Band Miniature Transceiver HNM01

    Ask Lasest Price
    Brand Name : hynall
    Model Number : HNM01
    Certification : RED, FCC, RoHS
    Price : To be negotiated
    Payment Terms : T/T
    Supply Ability : 35000pcs
    Delivery Time : 4 weeks
    • Product Details
    • Company Profile

    DC 12-30V Microwave Motion Sensor Module 5.8GHz C Band Miniature Transceiver HNM01

    Microwave Motion Sensor Module 5.8GHz C-band miniature transceiver HNM01


    Quick Detail:


    1. Cost efficient

    2. Ultra-small size


    Description:


    Low cost and super compact, flexible to be integrated into any suitable fixtures. 5V/12V/24V is be customized as your requirement.


    Size:


    Features:


    1. Antenna gain: 2 dBi, patch antenna.

    2. 2 balanced mixer.

    3. Output power: 5dBm EIRP .

    4. Receiver bandwidth: 1Hz ~ 2KHz.

    5. Operating current(CW mode): 13.5mA@5V.



    PIN Description:


    PINNameDescription
    1VCC5 0.25V DC
    2GND/
    3IF Output/
    4NCFix PIN
    5NCFix PIN
