HNB158DLPIR-C Zhaga Book 18 Bluetooth Mesh App Control Daylight Harvest PIR DALI-2 Motion Sensor

Ask Lasest Price
Brand Name :	hyanll
Model Number :	HNB158DLPIR-C
Payment Terms :	T/T
Supply Ability :	20000 per month
Delivery Time :	3~4 weeks

Add to Cart

Product Details
Company Profile

HNB158DLPIR-C Zhaga Book 18 Bluetooth Mesh App Control Daylight Harvest PIR DALI-2 Motion Sensor

Model name: HNB158DLPIR-C Zhaga book18 DALI & SILVAIR BLE PIR moion sensor

Feature:

Bluetooth operation frequency 2.4GHz-2.483GHz.

Bluetooth transmission power: 4dBm.

Bluetooth transmission range: 10-30m (Typical indoor).

Aux. sensor power supply:

Input voltage: 12-24V DC.

Input current: max. 25mA.

Self-contained DALI-2 bus power supply.

DALI-2 output (max. 4 devices), task tuning (1-100%).

Super compact size(o57 only), easy and small enough to be integrated.

Specially designed for UFO highbay fixtures, shoeboxes, wallpacks, streetlights, etc., simple plug and play.

If the lighting fixture manufacturers / contractors do

not want the sensor function, they just need to easily

remove the sensor head and put the cover cap on, the

fixture becomes standard non-sensor control fixture.

Autonomous sensor-based control.

OTA firmware upgrade.

Individual / group addressing.

Decentralized control (no single point of failure).

Detection range up to max. 16-18m in diameter.

Mounting height: max. 12m.

Operation temperature: -20 °c ~ +60 °c.

RoHS compliant.

IP rating: IP65.

Why Choose Us:

1. R&D strength:	10+ year experiences,alomost 100% success rate, Zhaga book20 series is comming soon.
2. Sales strength:	Professional sales,long term after-sale service promised.
3. Complete&strict QC system	many years experienced officers,complete QN system including IQC,IPQC,FQC,QN AND QE
4. Product quality	Under 0.1% defected rate. 5 years warranty
5. Certification:	CE,ROHS, ETL, FCC, RED
8. OEM/ODM ability:	Over 7 years OEM/ODM experience

Hynall SILVAIR motion sensor product list
Product	Daylight			Motion	Remark
Product	On/off	Daylight monitoring	Daylight harvest	Motion	Remark
HNB135PIR			✓	✓	0-10V output, special for indoor lighting
HNB135	converter				0-10V output, special for indoor lighting
HNB136	converter				0-10V output, special for indoor lighting
HNB136CCT	converter, tunable white function				0-10V output, special for indoor lighting
HNB156MW			✓	✓	MW+BLE, special design for outdoor lighting
HNB156	converter				BLE,special design for outdoor lighting
HNB158PIR			✓	✓	PIR+BLE, special design for outdoor lighting
HND150V/D	AC input, matching all of motion sensor head and converter of Zhaga book18 series

FAQ:

Q1, What is the warranty?

A: We offer a 5 year warranty along with a comprehensive after sale service.

Q2, Are the products certified?

A: Yes, we are fully certified for the EU, US and other markets. If you require any other forms of certificates, do get in touch.

Product Tags:

Zhaga Book 18 Motion Sensor

PIR DALI-2 Motion Sensor

Bluetooth mesh PIR Motion Sensor

HNB158DLPIR-C Zhaga Book 18 Bluetooth Mesh App Control Daylight Harvest PIR DALI-2 Motion Sensor
